AgXeed B.V.

AgBot 5.115T2

Logo AgXeed B.V.

Legal requirements given

Weight (kg)7800

Ground clearance (mm)420

Track width (mm)1900 - 3200mm

Speed (km/h)13

Power (kW)115

Request product

The largest AgBot available with crawler tracks is the draught horse for never-ending activities.

This AgBot with crawler track is a powerful tool for sustained work. Heavy pulling tasks can be performed fully autonomously, with high efficiency and gentle handling of the soil. The availability of a classic three-point linkage, standard interfaces and a variable track allows a wide range of actions on the land.

The AgXeed portal manages your entire operating cycle: fields and tasks, as well as your complete machine fleet.

You will appreciate the well-structured farm screen: you will find your plots logically organized by farm, field and subfields. A descending user management lets you decide who is allowed to connect to your digital farm. The digital barn houses your combinations of AgBots with implements, including their specific parameters.

Once the combinations are created, book them to a specific operation and the task is created. All tasks can be saved for later execution or sent immediately to the combination for execution. Once at the job site, start the operation with a safe and approved remote control. Once started, everything runs automatically. In the meantime, if you want to check on your machine, just turn on the camera remotely and see what's going on. That's what we call autonomy.

The AgBot 5.115T2 delivers a wide range of safety features

Safety precautions

  • Geofence System
  • Control lamps
  • Audible warning signals
  • Emergency stop buttons around the machine
  • Obstacle detection

  • LIDAR sensors on the top of the machine
  • Ultrasonic sensors integrated in the Safety Bumper
  • Radar sensors integrated in the Safety Bumper
  • Touch-sensitive sensors in the safety bumper integrated into the safety bumper
  • Machine size

  • Minimum length:2695 mm
  • Height:1800 mm
  • Overall length with hitch at 90 degree angle:3600 mm
  • Tare weight:7,8t
  • Gauge configuration

    Variable adjustment of the track width

  • Between 1900 and 3000 mm or 1900 - 3200 mm (depending on trolley type and track size)
  • Tracks from 300 mm - 910 mm width
  • Cutting height 42 cm
  • The AgXeed portal

    Manage, set up, control and collect data received from AgBots in one application from anywhere:

  • Setup:Configure your combinations of tractors and the AgBot with attachments.
  • Planning:Plan your tasks in advance, all season long
  • Control:Watch the AgBot at work on a map or via a camera.
  • Optimization:Use the collected data for better performance in upcoming tasks.
  • Pricing


    Upon request


    Do you want a specific price? Get your individual offer now!

    Request

    Attributes


    This information has been reviewed and verified by the manufacturer. All data without guarantee.

    Sensors

    Existing sensors

    Please fold out
    Obstacle detection system
    • LIDAR sensor on the top of the machine
    • Ultrasonic sensors integrated into the safety bumper
    • Radar sensors integrated into the safety bumper
    • Touch-sensitive bumper integrated in the safety bumper

    Support

    Phone support

    Mail support

    On-site support

    Remote maintenance

    Software

    Browser application

    The AgXeed portal manages your entire farm cycle: fields and tasks, as well as your complete machinery. You will appreciate the well-structured farm screen: you will find your plots logically organized by farm, field and subfields. A descending user management lets you decide who is allowed to connect to your digital farm. The digital barn houses your combinations of AgBots with attachments, including their specific parameters.
    Once the combinations are created, book them to a specific operation and the task is created. All tasks can be saved for later execution or sent immediately to the combination for execution. Once at the job site, start the operation with a safe and approved remote control. Once started, everything runs automatically. In the meantime, if you want to check on your machine, just turn on the camera remotely and see what's going on. That's what we call autonomy.

    Android-App

    iOS-App

    Place of data storage

    Cloud
    When the data has been sent from the cloud to the AgBot, it is stored locally on the machine (thus offline use is also possible)

    Tools

    Type of mounting for working tool

    Front hydraulics Cat.2, Rear hydraulics Cat.3

    Maximum lifting force (kg)

    8000
  • 8t in rear and 3t in front
  • Standard three-point

    Power take-off (PTO, PTO)

    Optional electric PTO (with up to 55 kW and 700 V)

    High voltage electrical connection

  • 700V
  • Crops

    on request

    Areas of application

    Examples: Preparation of the soil, sowing, preparation of the seedbed.
    AgBots are universally applicable machines that can act as "tractor replacements". They offer a wide range of possible applications, as they can be combined with almost all available attachments. The examples of use given are therefore only a fraction of what is possible.
    Preparation of the soil
    • Implement: 3m front knife roller and 3m 3 row cultivator
    • Speed: up to 10 km/h
    • Tiefe: 15cm
    • Soil: Sandy loam
    • Topography: flat
  • Seedbed preparation
    • Implement: 4m spring tine cultivator
    • Speed: 11 km/h
    • Soil: clay, limestone
    • Topography: gentle slopes
  • Sowing
    • Equipment: 3m front tender packer and 3m power harrow with maize precision seed drill
    • Speed: up to 8-12 km/h
    • Soil: Sandy loam - humus-rich loam
    • Topography: flat - gentle slopes

    Load-Sensing

    Locomotion

    Electric drive

    Diesel drive

    Other form of drive

    Diesel-electric

    Power (kW)

    115
    4.1l 4-cylinder Deutz diesel engine, stage 5 with 115kW / 156HP, max. torque of 610Nm

    Speed (km/h)

    13

    Tire options

    Rubber track with width from 300 mm to 910 mm

    Track width (mm)

    1900 - 3200mm
    Variable track width adjustment between 1,800 and 3,000mm or 1,800 - 3,200mm (adjustment range varies according to chassis type and track width)

    Ground clearance (mm)

    420

    Weight (kg)

    7800
    Specification refers to the unladen weight

    Transport system

    Low loader

    Legal requirements given

    Company


    Logo AgXeed B.V.

    AgXeed B.V.

    Niederlande

    Founding year:

    2018
